National Instruments Terminal Block I/O Connector – SCB-68 Used

National Instruments

$57.97

MSRP:

SKU: 000052524004U24Store-OS

Product Description

NI SCB-68 Shielded I/O Terminal Block Connector

Condition: Used, clean, and in good condition, with some cosmetic scratches and blemishes expected with this type of used equipment.

The National Instruments SCB-68 is a high-quality, shielded I/O terminal block connector designed to provide secure and noise-free connections for your NI DAQ devices. This versatile wire terminal block is ideal for a wide range of data acquisition applications, ensuring accurate and reliable signal transmission.

Key Features

  • Screw Terminals: Easy and secure I/O connections with screw terminals.
  • Shielded Design: Reduces noise and improves signal integrity.
  • Cold-Junction Compensation (CJC): Onboard sensor for accurate thermocouple temperature measurements.
  • General-Purpose Breadboard Areas: Flexible use with custom circuitry.

Specifications

  • Connector Type: 68-pin
  • Physical Dimensions:
    • Width: 18.1 cm (7.1 in.)
    • Depth: 15.2 cm (6.0 in.)
    • Height: 4.5 cm (1.8 in.)
    • Weight: 828 g (1 lb 13 oz)
  • Screw Terminal Wiring Specifications:
    • Minimum wire gauge: 30 AWG
    • Maximum wire gauge: 14 AWG
    • Screw terminal torque: 0.5 to 0.6 N-m (4 to 5 in.⋅lb)
    • Spacing between screw terminals: 5.00 mm (0.19685 in.)
  • Fuse Specifications: 800 mA, 250 VDC, Fast Blow, user-replaceable (Littelfuse P/N 235.800 or equivalent)

Compatibility

The SCB-68 is compatible with a wide range of NI DAQ devices, including:

  • NI 60xxE (formerly E Series)
  • NI 61xx (formerly S Series)
  • NI 62xx (formerly M Series)
  • NI 63xx (formerly X Series)
  • NI 66xx (formerly Timing I/O [TIO] Series)
  • NI 67xx (formerly Analog Output [AO] Series)
  • NI SC Express Models (PXIe-43xx)
  • NI High-Speed Digital I/O (HSDIO) or Digital Instruments (NI 653x)
  • NI Switches Models (NI 25xx)
  • NI R Series Models (NI 78xxR)

Additional Information

The SCB-68 does not offer panel, wall, or DIN rail mounting options. For more detailed information, you can refer to the user manuals and advanced function guides provided by National Instruments.

Specifications

  • Weight: 3 lb
  • Width: 10 in
  • Depth: 4 in
  • Height: 6 in
  • Noise shield: Easy wiring. Breadboard included. Enhances accuracy. Rugged build. Essential for data acquisition. Simplifies testing. Boosts measurement quality. Reliable performance.

0 reviews
